Identificação da Válvula
Condições Gerais - Inspeção Visual
Sedes/ObturadoresDanos, riscos, corrosão — Lapidação (reparo leve) ou substituição
CorpoTrincas — REJEITAR
Faces FlangesAcabamento, riscos, amassamentos — Conferir critério RL-5400.00-2000-200-PEI-401
HastesEmpenamento, corrosão — Endireitamento ou substituição
VolantesRompimento, trincas — Substituição
Roscas/PlugsDanificadas — Recuperação ou substituição
Placa de Identificação / TAGIlegível, ausente, TAG divergente do cadastro — Providenciar/regravar plaqueta com TAG correto
DocumentaçãoDocumentos faltantes ou desatualizados (Data Book, CLM, certificados) — Solicitar documentação ao fabricante/CONTRATANTE
Parafusos/Porcas (ASTM A193/A194)Revestimento eletrolítico proibido (Zn-Ni, Cádmio, Bicromatização, Galvanização) sem indicação contrária do projeto — Substituir por parafusos/porcas sem revestimento proibido, ou confirmar autorização explícita no projeto
Corrosão GeralProfunda (> 10% espessura) — Medição ultrassom + avaliação engenharia
Rastreabilidade do material confirmada (documentação OU análise de liga)
Medição de Espessura por Ultrassom (UT)
Só aplicável quando a corrosão visual identificada em "Corrosão Geral" (aba Condições Gerais - Inspeção Visual) for significativa (§9.1.2) — é uma medição/inspeção instrumentada, não uma verificação visual.
Região
Tipo de válvula (norma de espessura)
DN (mm)
Classe de Pressão
Espessura mínima (mm)
Espessura medida (mm)
Resultado
—
—
—
—
Inspeção Dimensional
Desmarque "Aplicável" quando a válvula/datasheet não especificar aquele parâmetro — o item some do cálculo de aprovado/reprovado e não conta como pendência. Tolerância em par +/-: pra normas simétricas (Face-Face, BCD) preencha os dois com o mesmo valor; pra normas assimétricas (Espessura da Aba, preenchida automática) os valores diferem de propósito.
Aplicável
Parâmetro
Nominal (mm)
Tol. + (mm)
Tol. − (mm)
Medido (mm)
Resultado
Observação
Comprimento Face-Face (F-F)
—
Diâmetro Externo do Flange (D)
—
Diâmetro do Círculo de Furação (BCD)
—
Diâmetro do Furo do Parafuso
—
Espessura da Aba do Flange
—
Diâmetro Interno (Bore) do Corpo
—
Altura Total da Válvula
—
Diâmetro do Eixo/Haste
—
Comprimento de Rosca da Haste
—
Diâmetro do Volante/Manípulo
—
Líquido Penetrante - LP
Região
Norma/Critério de Aceitação
Instrumento/Produto Utilizado
Resultado
Observação
Dureza
Região
Escala
Dureza Medida
Limite Máximo
Instrumento
Resultado
Observação
—
—
—
—
Teste de Estanqueidade das Sedes
Procedimento (API 598)
Limpeza pré-teste realizada (detritos e produtos de corrosão removidos da região das sedes)
Lubrificação com produtos compatíveis (sem silicone em serviço O₂/Cl₂)
Amaciamento — válvula ciclada 3 a 5× antes do teste
Montagem em bancada, válvula na posição de operação
Pressurização até a pressão de teste (água, ar ou N₂)
Tempo de estabilização ≥ 2 minutos antes da leitura
Reteste Hidrostático de Corpo/Sede — API 6D §10.3/10.4 (ET-005 §9.2.10)
Só aplicável quando o vazamento de sede não é solucionado após desmontagem/remontagem (§9.2.10) — marque "Reteste necessário" pra habilitar.
Fórmula: API 598 Tabela 5 — cruza DN + Tipo de sede + Meio de teste (+ Método de medição, se metal seated) → taxa máxima. Retenção: ml/min (líquido) ou m³/h (gás). Metal seated: ml/min ou gotas/min (líquido), ml/min ou bolhas/min (gás). Resiliente: vazamento zero (bubble-tight).
Válvula esfera — tipo especial
Teste Funcional
Bloqueio Manual (torquímetro, sem ferramenta de aumento de braço)
A ET-005 cita MSS SP-91 como fonte do limite de torque pra Gaveta/Globo/Retenção/Borboleta, mas o texto real da norma (Foreword) diz explicitamente que ela NÃO cobre valores de torque máximo/mínimo por válvula — isso é MAST (Maximum Allowable Stem Torque), dado específico do fabricante de cada válvula/atuador. Preencha o limite acima com o valor do datasheet/manual do fabricante.
PMI — Análise de Composição Química
Importe a leitura do equipamento, selecione as leituras desta válvula e gere o relatório de PMI — o vínculo de Rastreabilidade (§9.1.4, aba Condições Gerais) é preenchido automaticamente. Se o PMI já foi feito em outro relatório, use a busca por número na aba Condições Gerais em vez desta.
0análises livres
0selecionadas
0equipamentos
0N/S distintos
0materiais (ESP.MAT)
0aprovados
0%completude
DataHoraLeituraNomeDESCRICAOESP.MATIDN/SLAUDOLiga Detectada
Nenhuma leitura livre encontradaImporte um arquivo do equipamento acima e clique em Atualizar leituras disponíveis.
Campos de Laudo (§8.8.7)
Abrir RNC (Relatório de Não Conformidade)
Traz automaticamente os itens reprovados nos ensaios salvos dessa TAG — só falta classificar a severidade e o reparo.
Nenhuma RNC aberta aindaRNCs abertas para válvulas vão aparecer aqui.
Nenhum CRM emitidoCRMs (Comunicado de Rejeição de Material) aparecem aqui quando uma RNC severa é reprovada — emita pela aba RNC.
Consolidar RFI (Relatório Final de Inspeção)
Nenhum RFI emitidoLaudos finais consolidados por válvula vão aparecer aqui.
Inspeção Visual
Itens Verificados
Medição de Espessura (UT)
Itens Verificados
Dimensional
Itens Verificados
Líquido Penetrante - LP
Itens Verificados
Dureza
Itens Verificados
7.617resultados filtrados
441designações/normas
493UNS identificados
8elementos principais

Distribuição por família

Resultados

1–250 de 7.6171 / 31
Grau / TipoNormaUNSFamíliaCMnSiPSCrNiMo
Mín.Máx.Mín.Máx.Mín.Máx.Mín.Máx.Mín.Máx.Mín.Máx.Mín.Máx.Mín.Máx.
Grade 10122.1ASME SA-29/SA-29MG10120Aços carbono0,10000,15000,300,60———0,0400—0,0500——————
Grade 10122.1ASTM A29/A29M-12e1G10120Aços carbono0,10000,15000,300,60———0,0400—0,0500——————
Grade 10122.1ASTM A576-90b (2012)G10120Aços carbono0,10000,15000,300,60———0,0400—0,0500——————
C12D1.0311EN ISO 16120-2:2011—Aços carbono0,10000,15000,300,60—0,3000—0,0350—0,0350—0,20—0,25—0,05
C12D21.1124EN ISO 16120-4:2011—Aços carbono0,10000,15000,300,50—0,3000—0,0200—0,0250—0,10—0,10—0,05
Grade BL22.1GB 715-89—Aços carbono0,09000,15000,250,55—0,0700—0,0400—0,0400——————
Symbol S12C2.1JIS G 4051:2009—Aços carbono0,10000,15000,300,600,15000,3500—0,0300—0,0350—0,20—0,20——
Grade 10122.1SAE J403 JUN14G10120Aços carbono0,10000,15000,300,60———0,0400—0,0500——————
Grade 10152.1ASME SA-29/SA-29MG10150Aços carbono0,13000,18000,300,60———0,0400—0,0500——————
Grade 10162.1ASME SA-29/SA-29MG10160Aços carbono0,13000,18000,600,90———0,0400—0,0500——————
Grade 10152.1ASTM A29/A29M-12e1G10150Aços carbono0,13000,18000,300,60———0,0400—0,0500——————
Grade 10162.1ASTM A29/A29M-12e1G10160Aços carbono0,13000,18000,600,90———0,0400—0,0500——————
Grade 10152.1ASTM A576-90b (2012)G10150Aços carbono0,13000,18000,300,60———0,0400—0,0500——————
Grade 10162.1ASTM A576-90b (2012)G10160Aços carbono0,13000,18000,600,90———0,0400—0,0500——————
C15R1.1140EN 10084:2008—Aços carbono0,12000,18000,300,60—0,4000—0,03500,02000,0400——————
C15E1.1141EN 10084:2008—Aços carbono0,12000,18000,300,60—0,4000—0,0350—0,0350——————
C16E1.1148EN 10084:2008—Aços carbono0,12000,18000,600,90—0,4000—0,0350—0,0350——————
C16R1.1208EN 10084:2008—Aços carbono0,12000,18000,600,90—0,4000—0,03500,02000,0400——————
C15D1.0413EN ISO 16120-2:2011—Aços carbono0,12000,17000,300,60—0,3000—0,0350—0,0350—0,20—0,25—0,05
C15D21.1126EN ISO 16120-4:2011—Aços carbono0,13000,17000,300,50—0,3000—0,0200—0,0250—0,10—0,10—0,05
Grade 152.1GB/T 699-1999—Aços carbono0,12000,18000,350,650,17000,3700—————0,25—0,30——
Grade 15F2.1GB/T 699-1999—Aços carbono0,12000,18000,250,50—0,0700—————0,25—0,30——
Grade 15Mn2.1GB/T 699-1999—Aços carbono0,12000,18000,701,000,17000,3700—————0,25—0,30——
Grade 152.1GB/T 3078-94—Aços carbono0,12000,18000,350,650,17000,3700—————0,25—0,30——
Grade 15F2.1GB/T 3078-94—Aços carbono0,12000,1800—0,50—0,0700—0,0350—0,0350——————
Grade 15Mn2.1GB/T 3078-94—Aços carbono0,12000,18000,701,000,17000,3700—————0,25—0,30——
Grade 152.1GB 13791-92—Aços carbono0,12000,18000,350,650,17000,3700—————0,25—0,30——
Type C 16 M22.1ISO 683-11:1987—Aços carbono0,12000,18000,600,900,15000,4000—0,03500,02000,0400——————
Type C 16 E42.1ISO 683-11:1987—Aços carbono0,12000,18000,600,900,15000,4000—0,0350—0,0350——————
Type C 15 M22.1ISO 683-11:1987—Aços carbono0,12000,18000,300,600,15000,4000—0,03500,02000,0400——————
Type C 15 E42.1ISO 683-11:1987—Aços carbono0,12000,18000,300,600,15000,4000—0,0350—0,0350——————
Symbol S15C2.1JIS G 4051:2009—Aços carbono0,13000,18000,300,600,15000,3500—0,0300—0,0350—0,20—0,20——
Symbol S15CK2.1JIS G 4051:2009—Aços carbono0,13000,18000,300,600,15000,3500—0,0250—0,0250—0,20—0,20——
Grade 10152.1SAE J403 JUN14G10150Aços carbono0,13000,18000,300,60———0,0400—0,0500——————
Grade 10162.1SAE J403 JUN14G10160Aços carbono0,13000,18000,600,90———0,0400—0,0500——————
Grade 10172.1ASME SA-29/SA-29MG10170Aços carbono0,15000,20000,300,60———0,0400—0,0500——————
Grade 10182.1ASME SA-29/SA-29MG10180Aços carbono0,15000,20000,600,90———0,0400—0,0500——————
Grade 10192.1ASME SA-29/SA-29MG10190Aços carbono0,15000,20000,701,00———0,0400—0,0500——————
Grade 10172.1ASTM A29/A29M-12e1G10170Aços carbono0,15000,20000,300,60———0,0400—0,0500——————
Grade 10182.1ASTM A29/A29M-12e1G10180Aços carbono0,15000,20000,600,90———0,0400—0,0500——————
Grade 10192.1ASTM A29/A29M-12e1G10190Aços carbono0,15000,20000,701,00———0,0400—0,0500——————
Grade 10172.1ASTM A576-90b (2012)G10170Aços carbono0,15000,20000,300,60———0,0400—0,0500——————
Grade 10182.1ASTM A576-90b (2012)G10180Aços carbono0,15000,20000,600,90———0,0400—0,0500——————
Grade 10192.1ASTM A576-90b (2012)G10190Aços carbono0,15000,20000,701,00———0,0400—0,0500——————
C18D1.0416EN ISO 16120-2:2011—Aços carbono0,15000,20000,300,60—0,3000—0,0350—0,0350—0,20—0,25—0,05
C18D21.1129EN ISO 16120-4:2011—Aços carbono0,16000,20000,300,50—0,3000—0,0200—0,0250—0,10—0,10—0,05
Symbol S17C2.1JIS G 4051:2009—Aços carbono0,15000,20000,300,600,15000,3500—0,0300—0,0350—0,20—0,20——
Grade 10172.1SAE J403 JUN14G10170Aços carbono0,15000,20000,300,60———0,0400—0,0500——————
Grade 10182.1SAE J403 JUN14G10180Aços carbono0,15000,20000,600,90———0,0400—0,0500——————
Grade 10202.1ASME SA-29/SA-29MG10200Aços carbono0,18000,23000,300,60———0,0400—0,0500——————
Grade 10212.1ASME SA-29/SA-29MG10210Aços carbono0,18000,23000,600,90———0,0400—0,0500——————
Grade 10222.1ASME SA-29/SA-29MG10220Aços carbono0,18000,23000,701,00———0,0400—0,0500——————
Grade 10202.1ASTM A29/A29M-12e1G10200Aços carbono0,18000,23000,300,60———0,0400—0,0500——————
Grade 10212.1ASTM A29/A29M-12e1G10210Aços carbono0,18000,23000,600,90———0,0400—0,0500——————
Grade 10222.1ASTM A29/A29M-12e1G10220Aços carbono0,18000,23000,701,00———0,0400—0,0500——————
Grade 10202.1ASTM A576-90b (2012)G10200Aços carbono0,18000,23000,300,60———0,0400—0,0500——————
Grade 10212.1ASTM A576-90b (2012)G10210Aços carbono0,18000,23000,600,90———0,0400—0,0500——————
Grade 10222.1ASTM A576-90b (2012)G10220Aços carbono0,18000,23000,701,00———0,0400—0,0500——————
C22R1.1149EN 10083-2:2006—Aços carbono0,17000,24000,400,70—0,4000—0,03000,02000,0400—0,40—0,40—0,10
C22E1.1151EN 10083-2:2006—Aços carbono0,17000,24000,400,70—0,4000—0,0300—0,0350—0,40—0,40—0,10
C221.0402EN 10250-2:1999 C1:2000—Aços carbono0,17000,24000,400,70—0,4000—0,0450—0,0450—0,40—0,40—0,10
C20D1.0414EN ISO 16120-2:2011—Aços carbono0,18000,23000,300,60—0,3000—0,0350—0,0350—0,20—0,25—0,05
C20D21.1137EN ISO 16120-4:2011—Aços carbono0,18000,23000,300,50—0,3000—0,0200—0,0250—0,10—0,10—0,05
Grade 202.1GB/T 699-1999—Aços carbono0,17000,23000,350,650,17000,3700—————0,25—0,30——
Grade 20Mn2.1GB/T 699-1999—Aços carbono0,17000,23000,701,000,17000,3700—————0,25—0,30——
Grade BL32.1GB 715-89—Aços carbono0,14000,22000,300,60—0,0700—0,0400—0,0400——————
Grade 202.1GB/T 3078-94—Aços carbono0,17000,23000,350,650,17000,3700—————0,25—0,30——
Grade 20F2.1GB/T 3078-94—Aços carbono0,17000,2400—0,50—0,0700—0,0350—0,0350——————
Grade 20Mn2.1GB/T 3078-94—Aços carbono0,17000,23000,701,000,17000,3700—————0,25—0,30——
Grade 202.1GB 13791-92—Aços carbono0,17000,23000,350,650,17000,3700—————0,25—0,30——
Symbol S20C2.1JIS G 4051:2009—Aços carbono0,18000,23000,300,600,15000,3500—0,0300—0,0350—0,20—0,20——
Symbol S20CK2.1JIS G 4051:2009—Aços carbono0,18000,23000,300,600,15000,3500—0,0250—0,0250—0,20—0,20——
Grade 10202.1SAE J403 JUN14G10200Aços carbono0,18000,23000,300,60———0,0400—0,0500——————
Grade 10212.1SAE J403 JUN14G10210Aços carbono0,18000,23000,600,90———0,0400—0,0500——————
Grade 10222.1SAE J403 JUN14G10220Aços carbono0,18000,23000,701,00———0,0400—0,0500——————
Grade 10232.1ASME SA-29/SA-29MG10230Aços carbono0,20000,25000,300,60———0,0400—0,0500——————
Grade 10232.1ASTM A29/A29M-12e1G10230Aços carbono0,20000,25000,300,60———0,0400—0,0500——————
Grade 10232.1ASTM A576-90b (2012)G10230Aços carbono0,20000,25000,300,60———0,0400—0,0500——————
Symbol S22C2.1JIS G 4051:2009—Aços carbono0,20000,25000,300,600,15000,3500—0,0300—0,0350—0,20—0,20——
Grade 10232.1SAE J403 JUN14G10230Aços carbono0,20000,25000,300,60———0,0400—0,0500——————
Grade 10252.1ASME SA-29/SA-29MG10250Aços carbono0,22000,28000,300,60———0,0400—0,0500——————
Grade 10262.1ASME SA-29/SA-29MG10260Aços carbono0,22000,28000,600,90———0,0400—0,0500——————
Grade 10252.1ASTM A29/A29M-12e1G10250Aços carbono0,22000,28000,300,60———0,0400—0,0500——————
Grade 10262.1ASTM A29/A29M-12e1G10260Aços carbono0,22000,28000,600,90———0,0400—0,0500——————
Grade 10252.1ASTM A576-90b (2012)G10250Aços carbono0,22000,28000,300,60———0,0400—0,0500——————
Grade 10262.1ASTM A576-90b (2012)G10260Aços carbono0,22000,28000,600,90———0,0400—0,0500——————
C26D1.0415EN ISO 16120-2:2011—Aços carbono0,24000,29000,500,800,10000,3000—0,0300—0,0300—0,20—0,25—0,05
C26D21.1139EN ISO 16120-4:2011—Aços carbono0,24000,29000,500,700,10000,3000—0,0200—0,0250—0,10—0,10—0,03
Grade 252.1GB 13791-92—Aços carbono0,22000,29000,500,800,17000,3700—————0,25—0,30——
Grade 252.1GB/T 3078-94—Aços carbono0,22000,29000,500,800,17000,3700—————0,25—0,30——
Grade 25Mn2.1GB/T 3078-94—Aços carbono0,22000,29000,701,000,17000,3700—————0,25—0,30——
Grade 252.1GB/T 699-1999—Aços carbono0,22000,29000,500,800,17000,3700—————0,25—0,30——
Grade 25Mn2.1GB/T 699-1999—Aços carbono0,22000,29000,701,000,17000,3700—————0,25—0,30——
Grade C 252.1ISO 683-1:1987—Aços carbono0,22000,29000,400,700,10000,4000—0,0450—0,0450——————
Grade C 25 E42.1ISO 683-1:1987—Aços carbono0,22000,29000,400,700,10000,4000—0,0350—0,0350——————
Grade C 25 M22.1ISO 683-1:1987—Aços carbono0,22000,29000,400,700,10000,4000—0,03500,02000,0400——————
Symbol S25C2.1JIS G 4051:2009—Aços carbono0,22000,28000,300,600,15000,3500—0,0300—0,0350—0,20—0,20——
Grade 10252.1SAE J403 JUN14G10250Aços carbono0,22000,28000,300,60———0,0400—0,0500——————
Grade 10262.1SAE J403 JUN14G10260Aços carbono0,22000,28000,600,90———0,0400—0,0500——————
Grade 10292.1ASME SA-29/SA-29MG10290Aços carbono0,25000,31000,600,90———0,0400—0,0500——————
Grade 10292.1ASTM A29/A29M-12e1G10290Aços carbono0,25000,31000,600,90———0,0400—0,0500——————
Grade 10292.1ASTM A576-90b (2012)G10290Aços carbono0,25000,31000,600,90———0,0400—0,0500——————
Symbol S28C2.1JIS G 4051:2009—Aços carbono0,25000,31000,600,900,15000,3500—0,0300—0,0350—0,20—0,20——
Grade 10292.1SAE J403 JUN14G10290Aços carbono0,25000,31000,600,90———0,0400—0,0500——————
Grade 10302.1ASME SA-29/SA-29MG10300Aços carbono0,28000,34000,600,90———0,0400—0,0500——————
Grade 10302.1ASTM A29/A29M-12e1G10300Aços carbono0,28000,34000,600,90———0,0400—0,0500——————
Grade 10302.1ASTM A576-90b (2012)G10300Aços carbono0,28000,34000,600,90———0,0400—0,0500——————
Grade 302.1GB 13791-92—Aços carbono0,27000,34000,500,800,17000,3700—————0,25—0,30——
Grade 302.1GB/T 3078-94—Aços carbono0,27000,3400—0,60—0,2000—0,0350—0,0350——————
Grade 30Mn2.1GB/T 3078-94—Aços carbono0,27000,34000,701,000,17000,3700—————0,25—0,30——
Grade 302.1GB/T 699-1999—Aços carbono0,27000,34000,500,800,17000,3700—————0,25—0,30——
Grade 30Mn2.1GB/T 699-1999—Aços carbono0,27000,34000,701,000,17000,3700—————0,25—0,30——
Grade C 302.1ISO 683-1:1987—Aços carbono0,27000,34000,500,800,10000,4000—0,0450—0,0450——————
Grade C 30 E42.1ISO 683-1:1987—Aços carbono0,27000,34000,500,800,10000,4000—0,0350—0,0350——————
Grade C 30 M22.1ISO 683-1:1987—Aços carbono0,27000,34000,500,800,10000,4000—0,03500,02000,0400——————
Symbol S30C2.1JIS G 4051:2009—Aços carbono0,27000,33000,600,900,15000,3500—0,0300—0,0350—0,20—0,20——
Grade 10302.1SAE J403 JUN14G10300Aços carbono0,28000,34000,600,90———0,0400—0,0500——————
C32D1.0530EN ISO 16120-2:2011—Aços carbono0,30000,35000,500,800,10000,3000—0,0300—0,0300—0,20—0,25—0,05
C32D21.1143EN ISO 16120-4:2011—Aços carbono0,30000,34000,500,700,10000,3000—0,0200—0,0250—0,10—0,10—0,03
Symbol S33C2.1JIS G 4051:2009—Aços carbono0,30000,36000,600,900,15000,3500—0,0300—0,0350—0,20—0,20——
Grade 10342.1ASME SA-29/SA-29MG10340Aços carbono0,32000,38000,500,80———0,0400—0,0500——————
Grade 10352.1ASME SA-29/SA-29MG10350Aços carbono0,32000,38000,600,90———0,0400—0,0500——————
Grade 10372.1ASME SA-29/SA-29MG10370Aços carbono0,32000,38000,701,00———0,0400—0,0500——————
Grade 10342.1ASTM A29/A29M-12e1G10340Aços carbono0,32000,38000,500,80———0,0400—0,0500——————
Grade 10352.1ASTM A29/A29M-12e1G10350Aços carbono0,32000,38000,600,90———0,0400—0,0500——————
Grade 10372.1ASTM A29/A29M-12e1G10370Aços carbono0,32000,38000,701,00———0,0400—0,0500——————
Grade 10352.1ASTM A576-90b (2012)G10350Aços carbono0,32000,38000,600,90———0,0400—0,0500——————
Grade 10372.1ASTM A576-90b (2012)G10370Aços carbono0,32000,38000,701,00———0,0400—0,0500——————
C35R1.1180EN 10083-2:2006—Aços carbono0,32000,39000,500,80—0,4000—0,03000,02000,0400—0,40—0,40—0,10
C35E1.1181EN 10083-2:2006—Aços carbono0,32000,39000,500,80—0,4000—0,0300—0,0350—0,40—0,40—0,10
C351.0501EN 10083-2:2006—Aços carbono0,32000,39000,500,80—0,4000—0,0450—0,0450—0,40—0,40—0,10
C36D21.1145EN ISO 16120-4:2011—Aços carbono0,34000,38000,500,700,10000,3000—0,0200—0,0250—0,10—0,10—0,03
Grade 352.1GB/T 699-1999—Aços carbono0,32000,39000,500,800,17000,3700—————0,25—0,30——
Grade 35Mn2.1GB/T 699-1999—Aços carbono0,32000,39000,701,000,17000,3700—————0,25—0,30——
Grade 352.1GB/T 3078-94—Aços carbono0,32000,3900—0,60—0,2000—0,0350—0,0350——————
Grade 35Mn2.1GB/T 3078-94—Aços carbono0,32000,39000,701,000,17000,3700—————0,25—0,30——
Grade 352.1GB 13791-92—Aços carbono0,32000,39000,500,800,17000,3700—————0,25—0,30——
Grade C 352.1ISO 683-1:1987—Aços carbono0,32000,39000,500,800,10000,4000—0,0450—0,0450——————
Grade C 35 E42.1ISO 683-1:1987—Aços carbono0,32000,39000,500,800,10000,4000—0,0350—0,0350——————
Grade C 35 M22.1ISO 683-1:1987—Aços carbono0,32000,39000,500,800,10000,4000—0,03500,02000,0400——————
Symbol S35C2.1JIS G 4051:2009—Aços carbono0,32000,38000,600,900,15000,3500—0,0300—0,0350—0,20—0,20——
Grade 10352.1SAE J403 JUN14G10350Aços carbono0,32000,38000,600,90———0,0400—0,0500——————
Grade 10382.1ASME SA-29/SA-29MG10380Aços carbono0,35000,42000,600,90———0,0400—0,0500——————
Grade 10382.1ASTM A29/A29M-12e1G10380Aços carbono0,35000,42000,600,90———0,0400—0,0500——————
Grade 10382.1ASTM A576-90b (2012)G10380Aços carbono0,35000,42000,600,90———0,0400—0,0500——————
C38D1.0516EN ISO 16120-2:2011—Aços carbono0,35000,40000,500,800,10000,3000—0,0300—0,0300—0,20—0,25—0,05
C38D21.1150EN ISO 16120-4:2011—Aços carbono0,36000,40000,500,700,10000,3000—0,0200—0,0250—0,10—0,10—0,03
Symbol S38C2.1JIS G 4051:2009—Aços carbono0,35000,41000,600,900,15000,3500—0,0300—0,0350—0,20—0,20——
Grade 10382.1SAE J403 JUN14G10380Aços carbono0,35000,42000,600,90———0,0400—0,0500——————
Grade 10392.1ASME SA-29/SA-29MG10390Aços carbono0,37000,44000,701,00———0,0400—0,0500——————
Grade 10402.1ASME SA-29/SA-29MG10400Aços carbono0,37000,44000,600,90———0,0400—0,0500——————
Grade 10392.1ASTM A29/A29M-12e1G10390Aços carbono0,37000,44000,701,00———0,0400—0,0500——————
Grade 10402.1ASTM A29/A29M-12e1G10400Aços carbono0,37000,44000,600,90———0,0400—0,0500——————
Grade 10392.1ASTM A576-90b (2012)G10390Aços carbono0,37000,44000,701,00———0,0400—0,0500——————
Grade 10402.1ASTM A576-90b (2012)G10400Aços carbono0,37000,44000,600,90———0,0400—0,0500——————
C40E1.1186EN 10083-2:2006—Aços carbono0,37000,44000,500,80—0,4000—0,0300—0,0350—0,40—0,40—0,10
C40R1.1189EN 10083-2:2006—Aços carbono0,37000,44000,500,80—0,4000—0,03000,02000,0400—0,40—0,40—0,10
C401.0511EN 10083-2:2006—Aços carbono0,37000,44000,500,80—0,4000—0,0450—0,0450—0,40—0,40—0,10
C40D21.1153EN ISO 16120-4:2011--Aços carbono0,38000,42000,500,700,10000,3000—0,0200—0,0250—0,10—0,10—0,03
Grade 402.1GB 13791-92—Aços carbono0,37000,44000,500,800,17000,3700—————0,25—0,30——
Grade 402.1GB/T 3078-94—Aços carbono0,37000,4400—0,60—0,2000—0,0350—0,0350——————
Grade 40Mn2.1GB/T 3078-94—Aços carbono0,37000,44000,701,000,17000,3700—————0,25—0,30——
Grade 402.1GB/T 699-1999—Aços carbono0,37000,44000,500,800,17000,3700—————0,25—0,30——
Grade 40Mn2.1GB/T 699-1999—Aços carbono0,37000,44000,701,000,17000,3700—————0,25—0,30——
Grade C 402.1ISO 683-1:1987—Aços carbono0,37000,44000,500,800,10000,4000—0,0450—0,0450——————
Grade C 40 E42.1ISO 683-1:1987—Aços carbono0,37000,44000,500,800,10000,4000—0,0350—0,0350——————
Grade C 40 M22.1ISO 683-1:1987—Aços carbono0,37000,44000,500,800,10000,4000—0,03500,02000,0400——————
Symbol S40C2.1JIS G 4051:2009—Aços carbono0,37000,43000,600,900,15000,3500—0,0300—0,0350—0,20—0,20——
Grade 10392.1SAE J403 JUN14G10390Aços carbono0,37000,44000,701,00———0,0400—0,0500——————
Grade 10402.1SAE J403 JUN14G10400Aços carbono0,37000,44000,600,90———0,0400—0,0500——————
Grade 10422.1ASME SA-29/SA-29MG10420Aços carbono0,40000,47000,600,90———0,0400—0,0500——————
Grade 10432.1ASME SA-29/SA-29MG10430Aços carbono0,40000,47000,701,00———0,0400—0,0500——————
Grade 10422.1ASTM A29/A29M-12e1G10420Aços carbono0,40000,47000,600,90———0,0400—0,0500——————
Grade 10432.1ASTM A29/A29M-12e1G10430Aços carbono0,40000,47000,701,00———0,0400—0,0500——————
Grade 10422.1ASTM A576-90b (2012)G10420Aços carbono0,40000,47000,600,90———0,0400—0,0500——————
Grade 10432.1ASTM A576-90b (2012)G10430Aços carbono0,40000,47000,701,00———0,0400—0,0500——————
C42D1.0541EN ISO 16120-2:2011—Aços carbono0,40000,45000,500,800,10000,3000—0,0300—0,0300—0,20—0,25—0,05
C42D21.1154EN ISO 16120-4:2011—Aços carbono0,40000,44000,500,700,10000,3000—0,0200—0,0250—0,10—0,10—0,03
Symbol S43C2.1JIS G 4051:2009—Aços carbono0,40000,46000,600,900,15000,3500—0,0300—0,0350—0,20—0,20——
Grade 10422.1SAE J403 JUN14G10420Aços carbono0,40000,47000,600,90———0,0400—0,0500——————
Grade 10432.1SAE J403 JUN14G10430Aços carbono0,40000,47000,701,00———0,0400—0,0500——————
Grade 10442.1ASME SA-29/SA-29MG10440Aços carbono0,43000,50000,300,60———0,0400—0,0500——————
Grade 10452.1ASME SA-29/SA-29MG10450Aços carbono0,43000,50000,600,90———0,0400—0,0500——————
Grade 10462.1ASME SA-29/SA-29MG10460Aços carbono0,43000,50000,701,00———0,0400—0,0500——————
Grade 10442.1ASTM A29/A29M-12e1G10440Aços carbono0,43000,50000,300,60———0,0400—0,0500——————
Grade 10452.1ASTM A29/A29M-12e1G10450Aços carbono0,43000,50000,600,90———0,0400—0,0500——————
Grade 10462.1ASTM A29/A29M-12e1G10460Aços carbono0,43000,50000,701,00———0,0400—0,0500——————
Grade 10442.1ASTM A576-90b (2012)G10440Aços carbono0,43000,50000,300,60———0,0400—0,0500——————
Grade 10452.1ASTM A576-90b (2012)G10450Aços carbono0,43000,50000,600,90———0,0400—0,0500——————
Grade 10462.1ASTM A576-90b (2012)G10460Aços carbono0,43000,50000,701,00———0,0400—0,0500——————
C45E1.1191EN 10083-2:2006—Aços carbono0,42000,50000,500,80—0,4000—0,0300—0,0350—0,40—0,40—0,10
C45R1.1201EN 10083-2:2006—Aços carbono0,42000,50000,500,80—0,4000—0,03000,02000,0400—0,40—0,40—0,10
C451.0503EN 10083-2:2006—Aços carbono0,42000,50000,500,80—0,4000—0,0450—0,0450—0,40—0,40—0,10
C48D1.0517EN ISO 16120-2:2011—Aços carbono0,45000,50000,500,800,10000,3000—0,0300—0,0300—0,15—0,20—0,05
C46D21.1162EN ISO 16120-4:2011—Aços carbono0,44000,48000,500,700,10000,3000—0,0200—0,0250—0,10—0,10—0,03
C48D21.1164EN ISO 16120-4:2011—Aços carbono0,46000,50000,500,700,10000,3000—0,0200—0,0250—0,10—0,10—0,03
Grade 452.1GB 13791-92—Aços carbono0,42000,50000,500,800,17000,3700—————0,25—0,30——
Grade 452.1GB/T 699-1999—Aços carbono0,42000,50000,500,800,17000,3700—————0,25—0,30——
Grade 45Mn2.1GB/T 699-1999—Aços carbono0,42000,50000,701,000,17000,3700—————0,25—0,30——
Grade 452.1GB/T 3078-94—Aços carbono0,42000,4900—0,60—0,2000—0,0350—0,0350——————
Grade 45Mn2.1GB/T 3078-94—Aços carbono0,42000,50000,701,000,17000,3700—————0,25—0,30——
Grade C 452.1ISO 683-1:1987—Aços carbono0,42000,50000,500,800,10000,4000—0,0450—0,0450——————
Grade C 45 E42.1ISO 683-1:1987—Aços carbono0,42000,50000,500,800,10000,4000—0,0350—0,0350——————
Grade C 45 M22.1ISO 683-1:1987—Aços carbono0,42000,50000,500,800,10000,4000—0,03500,02000,0400——————
Symbol S45C2.1JIS G 4051:2009—Aços carbono0,42000,48000,600,900,15000,3500—0,0300—0,0350—0,20—0,20——
Symbol S48C2.1JIS G 4051:2009—Aços carbono0,45000,51000,600,900,15000,3500—0,0300—0,0350—0,20—0,20——
Grade 10442.1SAE J403 JUN14G10440Aços carbono0,43000,50000,300,60———0,0400—0,0500——————
Grade 10452.1SAE J403 JUN14G10450Aços carbono0,43000,50000,600,90———0,0400—0,0500——————
Grade 10462.1SAE J403 JUN14G10460Aços carbono0,43000,50000,701,00———0,0400—0,0500——————
Grade 10492.1ASME SA-29/SA-29MG10490Aços carbono0,46000,53000,600,90———0,0400—0,0500——————
Grade 10502.1ASME SA-29/SA-29MG10500Aços carbono0,48000,55000,600,90———0,0400—0,0500——————
Grade 10532.1ASME SA-29/SA-29MG10530Aços carbono0,48000,55000,701,00———0,0400—0,0500——————
Grade 10492.1ASTM A29/A29M-12e1G10490Aços carbono0,46000,53000,600,90———0,0400—0,0500——————
Grade 10502.1ASTM A29/A29M-12e1G10500Aços carbono0,48000,55000,600,90———0,0400—0,0500——————
Grade 10532.1ASTM A29/A29M-12e1G10530Aços carbono0,48000,55000,701,00———0,0400—0,0500——————
Grade 10492.1ASTM A576-90b (2012)G10490Aços carbono0,46000,53000,600,90———0,0400—0,0500——————
Grade 10502.1ASTM A576-90b (2012)G10500Aços carbono0,48000,55000,600,90———0,0400—0,0500——————
Grade 10532.1ASTM A576-90b (2012)G10530Aços carbono0,48000,55000,701,00———0,0400—0,0500——————
C50E1.1206EN 10083-2:2006—Aços carbono0,47000,55000,600,90—0,4000—0,0300—0,0350—0,40—0,40—0,10
C50R1.1241EN 10083-2:2006—Aços carbono0,47000,55000,600,90—0,4000—0,03000,02000,0400—0,40—0,40—0,10
C50D1.0586EN ISO 16120-2:2011—Aços carbono0,48000,53000,500,800,10000,3000—0,0300—0,0300—0,15—0,20—0,05
C50D21.1171EN ISO 16120-4:2011—Aços carbono0,48000,52000,500,700,10000,3000—0,0200—0,0250—0,10—0,10—0,03
Grade 502.1GB 13791-92—Aços carbono0,47000,55000,500,800,17000,3700—————0,25—0,30——
Grade 50Mn2.1GB 13791-92—Aços carbono0,48000,56000,701,000,17000,3700—————0,25—0,30——
Grade 502.1GB/T 3078-94—Aços carbono0,47000,55000,500,800,17000,3700—————0,25—0,30——
Grade 50Mn2.1GB/T 3078-94—Aços carbono0,48000,56000,701,000,17000,3700—————0,25—0,30——
Grade 502.1GB/T 699-1999—Aços carbono0,47000,55000,500,800,17000,3700—————0,25—0,30——
Grade 50Mn2.1GB/T 699-1999—Aços carbono0,48000,56000,701,000,17000,3700—————0,25—0,30——
Grade C 502.1ISO 683-1:1987—Aços carbono0,47000,55000,600,900,10000,4000—0,0450—0,0450——————
Grade C 50 E42.1ISO 683-1:1987—Aços carbono0,47000,55000,600,900,10000,4000—0,0350—0,0350——————
Grade C 50 M22.1ISO 683-1:1987—Aços carbono0,47000,55000,600,900,10000,4000—0,03500,02000,0400——————
Symbol S50C2.1JIS G 4051:2009—Aços carbono0,47000,53000,600,900,15000,3500—0,0300—0,0350—0,20—0,20——
Grade 10492.1SAE J403 JUN14G10490Aços carbono0,46000,53000,600,90———0,0400—0,0500——————
Grade 10502.1SAE J403 JUN14G10500Aços carbono0,48000,55000,600,90———0,0400—0,0500——————
Grade 10532.1SAE J403 JUN14G10530Aços carbono0,48000,55000,701,00———0,0400—0,0500——————
C52D1.0588EN ISO 16120-2:2011—Aços carbono0,50000,5500—0,50—0,8000—0,0300—0,0300—0,15—0,20—0,05
C52D21.1202EN ISO 16120-4:2011—Aços carbono0,50000,54000,500,700,10000,3000—0,0200—0,0250—0,10—0,10—0,03
Symbol S53C2.1JIS G 4051:2009—Aços carbono0,50000,56000,600,900,15000,3500—0,0300—0,0350—0,20—0,20——
Grade 10552.1ASME SA-29/SA-29MG10550Aços carbono0,50000,60000,600,90———0,0400—0,0500——————
Grade 10552.1ASTM A29/A29M-12e1G10550Aços carbono0,50000,60000,600,90———0,0400—0,0500——————
Grade 10552.1ASTM A576-90b (2012)G10550Aços carbono0,50000,60000,600,90———0,0400—0,0500——————
C55E1.1203EN 10083-2:2006—Aços carbono0,52000,60000,600,90—0,4000—0,0300—0,0350—0,40—0,40—0,10
C55R1.1209EN 10083-2:2006—Aços carbono0,52000,60000,600,90—0,4000—0,03000,02000,0400—0,40—0,40—0,10
C551.0535EN 10083-2:2006—Aços carbono0,52000,60000,600,90—0,4000—0,0450—0,0450—0,40—0,40—0,10
C56D1.0518EN ISO 16120-2:2011—Aços carbono0,53000,58000,500,800,10000,3000—0,0300—0,0300—0,15—0,20—0,05
C56D21.1220EN ISO 16120-4:2011—Aços carbono0,54000,58000,500,700,10000,3000—0,0200—0,0250—0,10—0,10—0,03
Grade 552.1GB/T 3078-94—Aços carbono0,52000,60000,500,800,17000,3700—————0,25—0,30——
Grade 552.1GB/T 699-1999—Aços carbono0,52000,60000,500,800,17000,3700—————0,25—0,30——
Grade C 552.1ISO 683-1:1987—Aços carbono0,52000,60000,600,900,10000,4000—0,0450—0,0450——————
Grade C 55 E42.1ISO 683-1:1987—Aços carbono0,52000,60000,600,900,10000,4000—0,0350—0,0350——————
